Product Variations

SWL-1550M-50 Optical Specifications

Sweeping Wavelength Range

1530 - 1580 nm

Spectral Tuning Range

50 nm typ.

Output CW Power

15 mW min.

SWL-1550M-60 Optical Specifications

Sweeping Wavelength Range

1525 - 1585 nm

Spectral Tuning Range

60 nm typ.

Output CW Power

10 mW min.

SWL-1550M-70 Optical Specifications

Sweeping Wavelength Range

1525 - 1590 nm

Spectral Tuning Range

70 nm typ.

Output CW Power

10 mW min.

Optical Specifications for All Models

Laser Linewidth

0.15 nm typ.

Output Power Variation

< ± 0.5 dB over full wavelength range

Optical Signal Noise Ratio

40 dB min.

Output Polarization

Depolarized

Fiber Type

SMF-28 with 900 μm jacket

Optical Connectors

FC/APC or SC/APC

Electrical Specifications

Sweep Voltage Input

12 V p-p typical

Sweep Frequency Bandwidth

Up to 2 KHz with proper driver electronics

Voltage Input Connector

SMA Female

Mechanical Specifications

Operating Temp. Range

-10° to -60° C

Power Supply

+12 V DC, 1 A max.

Power Consumption

12 W max.

Remote Control

Optional RS-232 for laser control & status monitoring

Display

LEDs for SWL On/Off, Power

Dimensions

210 mm x 125 mm x 28 mm

Connector (Power & RS-232)

DB-15 Female
