输出功率 Output Power (W)

20~100

工作方式 Working Mode

LD pumped, pulse

Q开关方式 Q-Switch

Acousto-Optic

光斑模式

Beam Mode

横模 Transverse

Quasi TEM00

纵模 Longitude

Multi-longitude

线宽 Spectral Linewidth (nm)

<0.1

偏振方式 Polarization

Line polarization

脉宽 Pulse width (ns)

~230 (typical, @ 15KHz)

重复频率 Repitition Rate (KHz)

15~50

峰值功率 Peak Power (KW)

27 (typical, @100W)

光束发散角Beam Divergence (full angle, mrad)

~3.5

光束直径Beam Diameter at Aperture (mm)

17 (ytpical)

光束椭圆度 Beam Roundness

>85%

功率稳定性Power Stability (RMS, over 4 hours)

<5%

尺寸 Dimensions (L×W×H, mm)

470X210X120

预热时间Warm-up Time (minutes)

<15

工作温度Operation Temperature (℃)

18~30

使用寿命Expected Lifetime (hours)

>10,000

保修期Warranty Time

1 year
