InfiniMite™系列有三款不同的倍率供您选择，带锁止功能，用以锁定倍率和调焦到固定位置。可对特定的视场成像，体积小，可安装在各种电子成像设备中。调焦时系统总长保持不变。
在使用1/3"SENSOR时，InfiniMite™镜头需在特定的工作距离和视场下工作。但是本镜头也可在2/3"SENSOR下使用。Alpha镜头使用在巨副显示场合，倍率在0.75X-0.08X之间。Beta和Gamma镜头用在Alpha镜头的后面，需要进行WD转换。比如，使用½"SENSOR,在相同的视场(0.5")和倍率的条件下，Alpha镜头的工作距离为40mm，而Beta镜头的工作距离为60mm,Gamma镜头的工作距离为122mm,6种镜头可广泛的应用在各种系统中。
| InfiniMite Alpha Specifications | |||||||
| Working Distance | 25mm | 40mm | 60mm | 80mm | 170mm | 230mm | 295mm |
| Primary Magnification | 0.75X | 0.50X | 0.33X | 0.25X | 0.13X | 0.10X | 0.08X |
| Field of View, ½" Sensor Horiz. | 8.5mm | 12.8mm | 19.4mm | 25.6mm | 51.2mm | 64.0mm | 80.0mm |
| Field of View, 1/3" Sensor Horiz. | 6.4mm | 9.6mm | 14.5mm | 19.2mm | 38.4mm | 48.0mm | 60.0mm |
| InfiniMite Beta Specifications | |||||||
| Working Distance | 55mm | 60mm | 90mm | 120mm | 240mm | 317mm | 400mm |
| Primary Magnification | 0.66X | 0.50X | 0.33X | 0.25X | 0.13X | 0.10X | 0.08X |
| Field of View, ½" Sensor Horiz. | 9.7mm | 12.8mm | 19.4mm | 25.6mm | 49.2mm | 64.0mm | 80.0mm |
| Field of View, 1/3" Sensor Horiz. | 7.3mm | 9.6mm | 14.5mm | 19.2mm | 36.9mm | 48.0mm | 60.0mm |
| InfiniMite Gamma Specifications | ||||||
| Working Distance | 122mm | 165mm | 213mm | 396mm | 515mm | 640mm |
| Primary Magnification | 0.50X | 0.33X | 0.25X | 0.13X | 0.10X | 0.08X |
| Field of View, ½" Sensor Horiz. | 12.8mm | 19.4mm | 25.6mm | 51.2mm | 64.0mm | 80.0mm |
| Field of View, 1/3" Sensor Horiz. | 9.6mm | 14.5mm | 19.2mm | 38.4mm | 48.0mm | 60.0mm |
