The 818-BB-27 High Speed UV Enhanced Silicon Optical Detector consists of a silicon detector with an enhanced ultraviolet response, making it well suited for the fourth harmonic Nd:YAG, YLF or Glass Lasers and Excimer Lasers. Additionally, its large 2.55 mm active diameter and 3ns rise time make it an excellent general-purpose biased detector for the 200 to 1100 nm wavelength region. To attain its fast response, this detector comes with a 24 VDC external power supply. 818-BB Series Biased Photodiode Detectors are cost effective diagnostic tools suitable for a variety of high speed applications such as viewing of Q-switched, mode-locked, or rapidly modulated laser signals and picosecond laser alignment.

• 光输入

  Free Space

• 探测器直径

  2.55 mm

• 探测器材料

  UV Enhanced Silicon

• 探测器类型

  PIN

• 接收角

  50°

• 波长范围

  200-1100 nm

• 带宽

  >118MHz

• 上升时间

  3ns

• 响应度

  0.56 A/W @ 830 nm

• 输出接头

  BNC

• 放大

  No

• 偏置电压/偏压

  24 V

• 截止频率

  200 MHz

• 暗电流

  <10nA

• 结电容

  <25 pF

• 测量类型

  Beam shape, frequency

• 反向击穿电压

  150 V

• NEP

  <0.1 pW/√Hz

• 下降时间

  3ns

• 饱和电流

  2.5 mA

• 螺纹类型

  8-32 and M4

818-BB-27高速紫外增强硅光学探测器由一个增强紫外响应的硅探测器组成，使其非常适合第四次谐波Nd:YAG、YLF或玻璃激光器和准分子激光器。此外，它的大的2.55毫米活动直径和3ns上升时间使它成为一个优秀的通用偏置探测器200至1100纳米波长区域。为了获得快速响应，该探测器配备了24伏直流外部电源。818-BB系列偏置光电二极管探测器是一种成本有效的诊断工具，适用于各种高速应用，如观察q开关、锁模或快速调制激光信号和微秒激光对准。
