The 818-BB-35 High Speed Biased Fiber-Optic Detector features a 1 meter long FC connectorized singlemode fiber coupled to a 1000 to 1650 nm InGaAs detector with a 0.032 mm active diameter and a <25 ps rise time. It includes a built-in bias supply consisting of two standard 3 V lithium cells (6V total bias) and a 50 ohm BNC connector output. It is a low-cost solution for ultra-fast measurements up to a 12.5 GHz bandwidth. This detectors are suitable for applications where detector rise time of <25 psec are required for Q-switched and Ultrafast Laser output analysis. The batteries are easily replaceable and by disconnecting the detector from the oscilloscope input, when not in use, you can extend the lifetime of the batteries. 818-BB Series Biased Photodiode Detectors are cost effective diagnostic tools suitable for a variety of high speed applications such as viewing of Q-switched, mode-locked, or rapidly modulated laser signals and picosecond laser alignment.

NOTE-These detectors are very susceptible to damage by electrostatic discharge (ESD). Please use ESD protective measures, like the FK-STRAP, when unpacking and handling these devices.

818-BB-35高速偏置光纤探测器具有1米长的FC连接单模光纤，与1000 - 1650 nm InGaAs探测器耦合，具有0.032 mm的活动直径和小于25 ps的上升时间。它包括一个内置的偏置电源，包括两个标准的3v锂电池(6V总偏置)和一个50欧姆BNC连接器输出。对于高达12.5 GHz带宽的超高速测量，这是一个低成本的解决方案。这种探测器适用于q开关和超快激光输出分析需要小于25 psec的探测器上升时间。电池很容易更换，通过将检测器从示波器输入端断开，在不使用时，可以延长电池的使用寿命。818-BB系列偏置光电二极管探测器是一种成本有效的诊断工具，适用于各种高速应用，如观察q开关、锁模或快速调制激光信号和微秒激光对准。注:这些探测器很容易受到静电放电(ESD)的损坏。在拆包和处理这些设备时，请使用ESD保护措施，比如FK-STRAP。
