The 818-BB-45F High Speed Battery Biased Fiber-Optic Detector features  a 1 meter long FC connectorized singlemode fiber coupled to a 400 to 900 nm GaAs high speed photodetector with a <30 ps rise time. It includes a built-in bias supply consisting of two standard 3 V lithium cells (6V total bias) and a 50 ohm BNC connector output. This cost effective diagnostic tool is suitable for a variety of high speed applications such as viewing of Q-switched, mode-locked, or rapidly modulated laser signals and picosecond laser alignment. It is a low-cost solution for ultra-fast measurements up to a 12.5 GHz bandwidth. This detectors are suitable for applications where detector rise time of <30 psec are required for Q-switched and Ultrafast Laser output analysis. The batteries are easily replaceable and by disconnecting the detector from the oscilloscope input, when not in use, you can extend the lifetime of the batteries.

NOTE-These detectors are very susceptible to damage by electrostatic discharge (ESD). Please use ESD protective measures, like the FK-STRAP, when unpacking and handling these devices.

818-BB-45F高速电池偏置光纤探测器具有1米长的FC连接单模光纤，与400 - 900 nm GaAs高速光电探测器耦合，上升时间<30 ps。它包括一个内置的偏置电源，包括两个标准的3v锂电池(6V总偏置)和一个50欧姆BNC连接器输出。这种成本有效的诊断工具适用于各种高速应用，如查看q开关、锁模或快速调制的激光信号和微微秒激光校准。对于高达12.5 GHz带宽的超高速测量，这是一个低成本的解决方案。这种探测器适用于q开关和超快激光输出分析需要的探测器上升时间小于30 psec的应用。电池很容易更换，通过将检测器从示波器输入端断开，在不使用时，可以延长电池的使用寿命。注:这些探测器很容易受到静电放电(ESD)的损坏。在拆包和处理这些设备时，请使用ESD保护措施，比如FK-STRAP。
