The 818-BB-21A 1.2 Ghz Optical Reciever consists of a free-space 300 to 1100 nm biased Silicon detector with a 0.40 mm diameter and a 500 ps rise time. It has a built-in amplifier with 26 dB of gain. It is excellent for viewing rapid modulation of low-power CW lasers or other light sources in the μW regime. The detector is AC coupled and features a bandwidth of up to 1.2 GHz. A wall plug-in style power supply is provided with this unit. 818-BB Series Biased Photodiode Detectors are cost effective diagnostic tools suitable for a variety of high speed applications such as viewing of Q-switched, mode-locked, or rapidly modulated laser signals and picosecond laser alignment.

NOTE-These detectors are very susceptible to damage by electrostatic discharge (ESD). Please use ESD protective measures, like the FK-STRAP, when unpacking and handling these devices.

• 探测器直径

  0.4 mm

• 3 dB 带宽

  30 kHz to 1.2 GHz

• 波长范围

  300-1100 nm

• 光输入

  Free Space

• 接收角

  10°

• 探测器材料

  Silicon

• 探测器类型

  PIN

• 最大转换增益

  450 V/W

• NEP

  60 pW/√Hz

• 上升时间

  500 ps

• 饱和电流

  1.3 mA

• 峰值响应度

  0.4 A/W @ 830 nm

• 偏置电压/偏压

  24 V

• 输出接头

  BNC

• 输出阻抗

  50 Ω

• 电源要求

  Includes AC adapter

• 螺纹类型

  8-32 and M4

818-BB-21A 1.2 Ghz光学接收器由一个300到1100纳米偏置硅探测器组成，直径0.40毫米，上升时间500 ps。它有一个内置放大器，增益26分贝。它是优秀的查看快速调制的低功率连续波激光或其他光源μW政权。探测器是交流耦合的，带宽高达1.2 GHz。本装置配有墙插式电源。818-BB系列偏置光电二极管探测器是一种成本有效的诊断工具，适用于各种高速应用，如观察q开关、锁模或快速调制激光信号和微秒激光对准。注:这些探测器很容易受到静电放电(ESD)的损坏。在拆包和处理这些设备时，请使用ESD保护措施，比如FK-STRAP。
