The 700-9-6.5 TO-can Temperature Controlled Laser Diode Mount provides a versatile mounting solution for the most demanding laser diode control in the laboratory. Direct access to the laser TO-can window is available using the 700-9-5.6 mount, for both the TO-9 and TO-56 can type. Optimum temperature control is achieved with two built-in 12.5 W Peltier thermoelectric coolers (TEC), and an optional water-cooled back plate, which increases low-end temperature capability. To increase system flexibility, the mounts incorporate nitrogen purge fitting, pre-drilled holes for mounting your circuitry, a BNC modulation port, and both thermistor and AD592CN temperature sensors.

• 包装类型

  3-pin & 4-pin TO-Can

• 温度传感器

  10 kΩ NTC Thermistor and AD592CN

• 端口类型

  Male 9-Pin DSUB (Diode) / Male 15-pin DSUB (TEC)

• 散热性能

  3 W

• 重量

  1.4 kg

700-9-6.5 to can温度控制激光二极管安装为实验室中要求最高的激光二极管控制提供了一种通用的安装解决方案。对于to -9和to -56 can型，可以使用700-9-5.6挂载直接访问激光to -can窗口。最佳的温度控制是通过两个内置的12.5瓦Peltier热电冷却器(TEC)和一个可选的水冷后板来实现的，后者提高了低端的温度能力。为了增加系统的灵活性，安装包括氮气吹扫配件，安装电路的预钻孔，BNC调制端口，热敏电阻和AD592CN温度传感器。
