The LD-1310-31B Fiber Coupled Laser Diode consists of Fabry-Perot lasers, having a fiber pigtail precisely attached for optimum coupling efficiency. This 1310 nm center wavelength version has a typical 1.5 mW of output power and includes a back facet photodiode. It is compatible with Newport’s 710 Temperature Controlled Mount. The 9/125 μm single-mode fiber pigtail is terminated with an FC style fiber optic connector. Applications include high-speed data and telecommunications systems and instrumentation and optical instruments requiring a laser diode light source. Backed by 30 day return-for-credit when the product is returned in the original sealed bag with no sign of physical damage. The product is highly ESD sensitive so a grounding wrist strap, like the FK-STRAP, is suggested to prevent damage.

• 类型

  Fiber Pigtailed Laser Diode

• 中心波长

  1310 nm

• 中心波长公差

  ±30 nm

• 输出功率

  1.5 mW

• 最大工作电流

  26 mA

• 阈值电流

  10 mA

• 上升/下降时间

  0.3 ns

• 包层直径

  125 µm

• 纤芯直径

  9 µm

• 工作温度

  -20 to 70°C

LD-1310-31B光纤耦合激光二极管由法布里-珀罗激光器组成，为了获得最佳耦合效率，它有一个精确的光纤辫子。这个1310nm的中心波长版本有一个典型的1.5 mW的输出功率，包括一个背面小面光电二极管。它与新港710温控安装兼容。9/125μm单模光纤辫子终止与FC风格光纤连接器。应用包括高速数据和电信系统以及需要激光二极管光源的仪器和光学仪器。在没有任何物理损坏迹象的情况下，当产品被退回到原来的密封袋中时，有30天的退款。该产品是高度ESD敏感的，所以建议一个接地腕带，如fk带，以防止损害。
