The HL8340MG-A TO-56 Laser Diode is a popular Fabry-Perot laser diode with a typical center wavelength of 852 nm, and 40 mW of output power in a standard TO-56 package. It is single mode, which ensures focusing into a small spot size, high coupling into optical fibers, and good collimation, as opposed to multimode lasers. With the Newport’s industry renowned laser mounts, laser diode drivers, diode temperature controllers you can easily build a reliable and low noise laser system with maximum output power and wavelength flexibility. Backed by 30 day return-for-credit with the products returned in the original sealed bag with no physical damage.

• 类型

  CW Laser Diode

• 中心波长

  852 nm

• 中心波长公差

  ±10 nm

• 输出功率

  40 mW

• 光束发散角（全角）

  2.44:1

• 最大工作电流

  100 mA

• 阈值电流

  20 mA

• 尺寸

  TO-56

• 线宽

  < 1nm

HL8340MG-A到56激光二极管是一种很受欢迎的法布里-珀罗激光二极管，典型的中心波长为852 nm，输出功率为40mw，标准的TO-56封装。它是单模的，这确保聚焦成一个小的光斑大小，高耦合到光纤，和良好的准直，与多模激光器不同。与新港的行业著名激光支架，激光二极管驱动器，二极管温度控制器，你可以轻松建立一个可靠的低噪音激光系统最大的输出功率和波长灵活性。以30天退款为担保，产品在原封不动的密封袋中退回。
