The M-10X microscope objective has a 10x magnification, 0.25 numerical aperture, 16.5 mm focal length, and 7.5 mm clear aperture. It uses a standard RMS thread, 0.800-36. The objective is corrected for a rear conjugate at 160 mm. The lenses are antireflection coated with MgF2 for the visible spectrum. This M-10x objective is suitable for use with either the Model 900 or 910A spatial filters. M- series microscope objective power is based on a 160 mm tube length. MP = 160 mm/f

• 物镜类型

  Microscope

• 放大率

  10x

• 数值孔径

  0.25

• 波长范围

  400-700 nm

• 有效焦距

  16.5 mm

• 工作距离

  5.5 mm

• 套管透镜焦距

  160 mm

• 通光孔径

  7.5 mm

M-10X显微镜物镜具有10倍放大，0.25数值孔径，16.5 mm焦距，7.5 mm透明孔径。它使用一个标准的RMS线程，0.800-36。目标是纠正后共轭在160毫米。镜片表面涂有MgF2的抗反射涂层，用于可见光光谱。这个M-10x物镜适用于900或910A型空间滤波器。M系列显微镜物镜放大镜是基于160mm管的长度。MP = 160mm /f
