| 型号 | C9920-02G |
| PL 波长测量范围 | 300 nm to 950 nm |
| 单色光源：光源 | 150 W Xenon light source |
| 单色光源：激发波长 | 250 nm to 950 nm |
| 单色光源：带宽 | Approx. 2 nm to 5 nm (Varies with slit) |
| 单色光源：通过光降低样品的降解 | Excitation light interception by the mechanical shutter |
| 单色光源：激发波长控制 | Automatic control |
| 多通道光谱仪：测量波长范围 | 200 nm to 950 nm |
| 多通道光谱仪：波长分辨率 | < 2 nm |
| 多通道光谱仪：光敏器件通道数 | 1024 ch |
| 多通道光谱仪：设备制冷温度 | -15 ˚C |
| 多通道光谱仪：AD 分辨率 | 16 bit |
| 多通道光谱仪：光谱仪光学布置 | Czerny-Turner type |
| 多通道光谱仪：光纤类型 | Bundled fiber (1.5 m) |
| 多通道光谱仪：光纤接收面积 | Φ1 mm |
| 积分球：材料 | Spectralon |
| 积分球：尺寸 | 3.3 inch |
| 样品盒 (选项)：薄膜 | Using Laboratory dish without caps (5 sets) A10095-01 (not including a substrate) |
| 样品盒 (选项)：粉末 | Using Laboratory dish with caps (5 sets) A10095-03 |
| ——溶解 (正常温度) | Using Alignment tool for liquid measurement A10104-01 |
| ——溶解 (低温) | -196 ˚C (77 K) by using Sample holder for low temperature A11238-01 |
| ——温度控制 | RT(Room
temperature) to +300 ˚C by using Sample holder for temperature control
A13924-03 with Controller for temperature control C13923-01 |
| 样品盒（选项）：粉末 | Using Laboratory dish with caps (5 sets) A10095-03 |
| ——溶解 (正常温度) | Using Side-arm cell (3 sets) A10095-02 |
| ——溶解 (低温) | -196 ˚C (77 K) by using Sample tube for low temperature measurement (5 pcs) A10095-04 |
| 测量项目 | PL
quantum yield Fluorescent materials luminance efficiency measurement
(quantum yield x absorption) Excitation wavelength dependence of quantum
yield (-02G, -03G) PL spectrum (peak wavelength, FWHM) PL excitation
spectrum (-02G, -03G) Color measurement (chromaticity, color
temperature, color rendering index, etc.) Self-absorption correction
(Optics for transmission and fluorescence measurement A11238-03 is
required) |
