The M1Q Mirror Mount is ideal for general purpose applications requiring a compact, robust, kinematic design at an economical price. The M1Q has a clear edge-aperture for 1 inch (25.4 mm) diameter optics. UPA-series adaptors, which are compatible with the M1 mount, allow other various sizes and types of optics to be securely held and positioned. Two precision 100-TPI adjustment screws are standard providing exceptionally smooth, high-resolution adjustment.

• 镜片直径

  25.4 mm

• 驱动方式

  Knob, non-locking

• 调节

  θx, θy

• 灵敏度

  3.8 arc sec

• 特殊功能

  Clear Edge

• 角范围

  ±4°

• 调节螺纹

  100 TPI

• 材料

  Coated Aluminum

• 机制

  Kinematic

• 螺纹类型

  8-32 (M4) CLR

M1Q镜像安装是理想的一般用途的应用，要求紧凑，健壮，运动设计在一个经济的价格。M1Q有一个清晰的边缘孔径为1英寸(25.4毫米)直径光学。UPA-series适配器，与M1安装兼容，允许其他各种尺寸和类型的光学器件安全地保持和定位。两个精密的100-TPI调整螺丝是标准提供异常平滑，高分辨率调整。
