The CONEX-AG-PR100P is a piezo motor rotary stage with direct encoder feedback and closed-loop piezo motor controller/driver. Initially targeted for repeatable positioning of polarizing optics, it can also be used as a miniature rotation stage for precision positioning of other optics or lightweight samples.
The Agilis AG-PR100P rotary stage comes with a built-in direct read encoder, enabling high angular position repeatability. The footprint is maintained while delivering 0.002° uni-directional repeatability expected from direct read encoder technology. The rotary stage is very compact, but is capable of 340° travel, and 0.001° MIM.

The CONEX-AGP closed-loop algorithm is a simplified version of the typical DC servo loop algorithm, and combined with the rotary encoder, provides a system uni-directional repeatability of 0.002°. For stability in-position, the user can adjust the dead band parameter that stops dithering when the stage is within a set position tolerance.


The CONEX-AGP is a very compact and inexpensive single axis motion controller and is delivered already pre-configured for the stage.
For OEM applications, an optional retainer to secure the USB and power cables is available. In addition, RS232 and RS485 communication is available at the board level.


conex ag - pr100p是一个压电马达的旋转平台，具有直接编码器反馈和闭环压电马达控制器/驱动器。它最初定位于偏振光学的可重复定位，也可作为其他光学或轻质样品精密定位的微型旋转平台。

Agilis AG-PR100P旋转台内置直读编码器，具有较高的角度位置可重复性。足迹是维护而交付0.002°单向重复性预期从直接读取编码器技术。扶轮阶段非常紧凑,但能够340°旅行,和0.001°MIM。

CONEX-AGP闭环算法是一种典型的直流伺服回路的简化版本的算法,并结合旋转编码器,提供了一个系统单向重复性0.002°。为了稳定位置，用户可以调整死带参数，当舞台在设定的位置公差内停止抖动。

CONEX-AGP是一个非常紧凑和廉价的单轴运动控制器，并已交付预先配置为舞台。

对于OEM应用程序，一个可选的保持器来保护USB和电源电缆是可用的。此外，RS232和RS485通信可在董事会一级获得。
