Designed for DC brushless motors, the XPS-EDBL is a 3-phase sinusoidal motor driver (amplifier) which features 25A peak current and +96V DC voltage, up to 1,000 watts of permanent power when optional fans are mounted. The high power, enables the XPS-EDBLto fully utilize the motor further maximizing the stage performance.
The XPS-EDBL high-power driver is also well suited for use in an Industrial Environment. The driver is fully protected with a 150W power resistor to dissipate regeneration energy (back EMF) and two optional fans limit the temperature increase.

• SP 兼容性

  ESP Stage Detection

• 轴数

  1

• 重量

  6.7 kg

XPS-EDBL是一款专为直流无刷电机设计的三相正弦电机驱动(放大器)，具有25A峰值电流和+96V直流电压，可选风扇安装时可提供高达1000瓦的恒功率。大功率，使xps - edblb充分利用电机进一步最大化的舞台性能。XPS-EDBL大功率驱动器也非常适合在工业环境中使用。驱动完全保护与150W功率电阻耗散再生能量(反电动势)和两个可选风扇限制温度的增加。
