355nm灯泵浦激光器
LPS-355-L200mj
| Wavelength (nm)波长 | 355± 1 | ||
| Operating mode工作方式 | Q-switched : EOM (Electro-optic modulation) | ||
| Single pulse energy (mJ)单脉冲能量 | 100 | 150 | 200 |
| Pulse duration (ns)脉宽 | < 10 | ||
| Rep. rate (Hz)频率 | 1~ 10 (adjustable) | ||
| Energy stability能量稳定性 | <5%, <3% | ||
| Beam divergence, full angle (mrad)发散角 | <3 | ||
| Beam diameter (mm)光斑 | ~7 | ||
| Warm-up time (minutes)上升温度 | < 15 | ||
| Beam height from base plate (mm)中心高 | 80 | ||
| Cooled method制冷 | Water Cooled | ||
| Operating temperature (℃)工作温度 | 15~35 | ||
| Power supply (220/ 110VAC)电源 | 220v | ||
| Expected lifetime (pulses)寿命 | 108 | ||
| Warranty period保修 | 1 year | ||
| Available Options | Higher repetition rates:≤20Hz; Jitter :~1ns (Sdev); Accessories | ||
