355nm大功率连续激光器
LL355-300mw
All solid-state CW mode UV laser is made features of ultra compact, easy operating, high power and staiblity, which is perfect for flow cytometry, spectrum analysis, microscopy, semiconductor inspection, cell sorting, optical instrument, , physics experiment, etc.
| Wavelength (nm)波长 | 355±1 |
| Operating mode工作方式 | CW |
| Output power (mW)输出功率 | 30-300 |
| Power stability (rms, over 4 hours)功率稳定性 | <3%, <2% |
| Transverse mode出光模式 | Near TEM00 |
| Beam diameter at the aperture (1/e2, mm)光斑尺寸 | <3.0 |
| Beam divergence, full angle (mrad)发散角 | <6.0 |
| Polarization Ratio偏振比啊 | >50:1 Horizontal (Vertical Optional) |
| Spectral purity | >99% |
| Warm-up time (minutes)上升温度 | <10 |
| Pointing stability after warm-up (mrad)光束指向稳定性 | <0.05 |
| Cooled method (Water cooled)水冷 | 580 |
| Beam height from base plate (mm)中心高 | 52.4 |
| Operating Temperature (°C)工作温度 | 10-35 |
| Modulation optional调制 | TTL on/off, 1Hz- 1KHz, 1KHz- 10KHl |
| Power supply (90-264VAC)供电 | 供电 |
| Warranty保修 | 1 year |
