266 nm皮秒脉冲紫外激光器
LLPSR266-50mw
| SPECIFICATIONS | |||
| Wavelength (nm)波长 | 266±1 | ||
| Operating mode出光模式 | Mode-locked | ||
| Output power (mW) | @ Mode-locked mode功率 | > 1, 5, 10, ... , 50 | |
| Power stability (rms, over 4 hours)功率稳定性 | <3%, <5% | ||
| Transverse mode光斑模式 | TEM00 | ||
| Pulse duration(ps)脉宽 | 10~20 | ||
| Rep.rate(MHz)频率 | 48±1 | ||
| Beam divergence, full angle (mrad)发散角 | <4 | ||
| Beam diameter at the aperture ( 1/e2,mm)光斑尺寸 | ~3 | ||
| Beam height from base plate (mm)中心高 | 60 | ||
| Warm-up time (minutes)上升时间 | <20 | ||
| Operating temperature (C)工作温度 | 10~30 | ||
| Power Supply(90-264VAC)电源 | 220v数显可调 | ||
| Expected lifetime (hours)寿命 | 10000 | ||
| Warranty period保修 | 1 year | ||
