266nm光纤激光器
       LLGX266-50mw



Wavelength (nm)波长266± 1
Operating mode工作方式Pulsed
Output power (mW)功率10@ 1MHz50@ 1MHz
Power stability (rms, over 4 hours)功率稳定性<5%, <3%
Pulse width (ps)( 1)脉宽One fixed value between 50~900ps
M2 factor光束质量<2
Repetition frequency(MHz)(2)One fixed value between 0. 1-20MHz
Polarization ratio偏振比> 15dB
Warm-up time (minutes)上升温度< 15
Beam height from base plate (mm)中心高40
Delivery cable length(cm)60
Operating temperature (C)工作温度15~35
Power supply供电220V AC/ 12V DC
Expected lifetime (hours)寿命10000
Warranty保修1 year
Options( 1)  Pulse width 50~900ps variable or <50ps can be customized.
(2)  Repetition rate 0. 1~20MHz variable or 1Hz~1kHz can be customized. RS 232 interface
Higher output power can be customized
