343nm脉冲激光器
LLQ343-50mw

Wavelength (nm)波长343±1
Operating mode工作方式Frequency conversion of Q-switched pulsed laser
Max average power (mW)*功率1~50
Single pulse energy (µJ)单脉冲能量0. 1~7
Pulse duration (ns)脉宽~7
Peak power (kW)峰值功率0.01~ 1
Rep. rate (kHz)QCW脉冲频率Between 4k-8kHz.
Ave power stability (over 4 hours)功率稳定性<5%, <3%
Transverse mode光斑模式Near TEM00
M2 factor光束质量<2.0
Beam diameter at the aperture (mm)光斑尺寸Elliptical (4:1), Beam spot 0.5*2mm
Polarization ratio偏振比>50:1, Horizontal (Vertical Optional)
Warm-up time (minutes)预热时间<5
Beam height from base plate (mm)中心高70
Operating temperature (°C)工作温度10~35
Power supply (90-264VAC)电压220v
Warranty寿命1 year
