303nm脉冲激光器
LLQ303-10mw
| Wavelength (nm)波长 | 303± 1 |
| Operating mode工作方式 | Acousto-Optics Q-switched |
| Max average power (mW)*平均功率 | 1- 10@5kHz |
| Single pulse energy (μJ)能量 | 1-2@5kHz |
| Pulse duration(varies from power and repetition.)脉宽 | ~20ns@5kHz |
| Peak power(kW)峰值功率 | ~0. 1 |
| Rep. rate (kHz)频率 | 1- 10kHz |
| Power Stability (rms,over 4 hours)功率稳定性 | <5%, <3% |
| Transverse mode光斑模式 | TEM00 |
| Beam Diameter at the aperture 1/e2 (mm)光斑尺寸 | ~ 1.5 |
| Beam divergence, full angle (mrad)发散角 | <2.0 |
| Warm-up Time (minutes)预热时间 | < 10 |
| Operating temperature(℃)工作温度 | 10~35 |
| Cooled method制冷 | Water Cooled |
| Expected lifetime (hours)使用寿命 | 10000 |
| Warranty保修 | 1 year |
