213nm皮秒激光器
| Model型号 | LLMPS-213 |
| Wavelength (nm)波长 | 213± 1 |
| Operating mode工作模式 | Q-switched pulsed laser |
| Max average power (mW)*输出功率 | ~80 |
| Single pulse energy (µJ)单脉冲能量 | ~20 |
| Pulse duration (ps)脉宽 | ~ 1000 |
| Peak power (kW)峰值功率 | 20 |
| Rep. rate (kHz) (optional)频率 | 1~4 |
| Ave power stability (over 4 hours)功率稳定性 | <5%, <3%, <2% |
| Transverse mode光斑模式 | TEM00 |
| Beam diameter at the aperture (mm)光斑 | ~ 1.5 |
| Beam divergence, full angle (mrad)发散角 | < 1.5 |
| Warm-up time (minutes)上升时间 | <5 |
| Beam height from base plate (mm)中心高 | 32 |
| Cooled method (Fan Cooled)制冷 | TC |
| Operating temperature (C)工作温度 | 15~30 |
| Expected lifetime (hours)寿命 | 10000 |
| Warranty保修 | 1 year |
