320nm低噪声激光器
LLDZS320-400mw
| Central wavelength (nm)波长 | 320± 1 |
| Operating mode输出模式 | CW |
| Output power (mW)输出功率 | 1-400 |
| Power stability (rms, over 4 hours)功率稳定性 | <3%, <2% |
| Transverse mode光斑模式 | Near TEM00 |
| Beam diameter at the aperture ( 1/e2, mm)光斑 | <3.0 |
| Noise of amplitude (rms, 1Hz~20MHz)噪声 | < 1% |
| Beam divergence, full angle (mrad)发散角 | < 10 |
| Warm-up time (minutes)上升时间 | < 10 |
| Polarization Ratio偏振比 | >50:1, Horizontal (Vertical Optional) |
| Beam height from base plate (mm)中心高 | 94 |
| Cooled method (Water Cooled)制冷 | 水冷 |
| Operating temperature (C)工作温度 | 10~35 |
| Power supply供电 | 12V DC (Photoelectric integrated) |
| Warranty保修 | 1 year |
