601nm激光器
LLQ-250mw
LD PUMPED ALL-SOLID-STATE Q-SWITCHED LASER at 601nm All solid state Q-switched laser at 601nm has the features of ultra compact, easy operating, which is widely used in micro-electronics, metrology and material processing ,laser medical treatment, scientific experiment, etc
| Central wavelength (nm) | 601±2 |
| Operating mode | Acousto-Optic Q-switched |
| Average power (mW) | 1~250 |
| Rep. rate (kHz) | 10 |
| Pulse duration (ns) | < 10 |
| Single pulse energy (µJ) | 1~25 |
| Peak power(kW) | 2.5 |
| Beam diameter at the aperture ( 1/e2,mm) | <3 |
| Beam divergence, full angle (mrad) | <2 |
| Power stability (rms, over 4 hours) | <3%, <5% |
| Beam height from base plate (mm) | 120 |
| Warm-up time (minutes) | < 10 |
| Power supply | PSU-AOM (3U) |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
