582nm激光器
LL582-100mw
LD PUMPED ALL-SOLID-STATE YELLOW LASER All solid state at 582nm blue laser features of ultra compact, long lifetime, low cost and easy operating, which is used in laser display, medical treatment, scientific research, etc.
| Wavelength (nm) | 582±2 |
| Operating mode | CW |
| Output power (mW) | > 10, 20, ..., 100 |
| Power stability (rms, over 4 hours) | <3%, <5% |
| Transverse mode | Near TEM00 |
| Beam divergence, full angle (mrad) | <3 |
| Beam diameter at the aperture ( 1/e2,mm) | ~4 |
| Polarization ratio | > 100:1 |
| Beam height from base plate (mm) | 100 |
| Warm-up time (minutes) | < 10 |
| Operating temperature (C) | 15~30 |
| Power supply (90-264VAC) | PSU-W-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
