577nm激光器
LL577-1200mw
LD PUMPED ALL-SOLID-STATE YELLOW LASER AT 577nm All solid state 577 nm yellow laser is made features of ultra compact, long lifetime and easy operating, which is widely used in collimation, laser medical treatment, scien
| Part number | LL577-1200mw |
| Wavelength (nm) | 577±2 |
| Operating mode | CW |
| Output power (mW) | 600- 1200 |
| Power stability (rms, over 4 hours) | <3%, <2%, < 1% |
| Transverse mode | Multi mode |
| M2 factor | <2.0 |
| Beam diameter at the aperture ( 1/e2, mm) | <2.5 |
| Beam divergence, full angle (mrad) | < 1.5 |
| Polarization Ratio | > 100:1, (Horizontal or Vertical Optional) |
| Warm-up time (minutes) | <5 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating Temperature (°C) | 10-35 |
| Modulation option | TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz |
| Power supply (90-264VAC) | PSU-H-LED |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
