558nm激光器
LL558-500mw
LD PUMPED ALL-SOLID-STATE YELLOW LASER AT 558nm All solid state 558 nm yellow green laser is made features of ultra compact, long lifetime and easy operating, which is widely used in laser medical treatment, scientific experiment, optical instrument, etc.
| Part number | LL558-500mw |
| Wavelength (nm) | 558± 1 |
| Operating mode | CW |
| Output power (mW) | 1-500 |
| Power stability (rms, over 4 hours) | <3%, <2%, < 1% |
| Transverse mode | TEM00 |
| M2 factor | < 1.2 |
| Beam diameter at the aperture ( 1/e2, mm) | <2.0 |
| Beam divergence, full angle (mrad) | 1.5 |
| Polarization Ratio | > 100:1, (Horizontal or Vertical Optional) |
| Warm-up time (minutes) | <5 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating Temperature (°C) | 10-35 |
| Modulation option | TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz, |
| Power supply (90-264VAC) | PSU-H-LED/ |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
