450nm皮秒激光器
LLPD450-60mw
PICOSECOND PULSED BLUE DIODE LASER AT 450nm
It features integrated electronics, repetition rate 100kHz to 80MHz, synchronized signal output. Fast ON/ OFF/ multiplexing capability. Suitable for fluorescence excitation, time resolve spectrum, highly sensitive absorption spectroscopy, etc.
| Central wavelength (nm) 中心波长 | 450±5 | |
| Operating mode 输出方式 | Pulsed | |
| Peak power (mW)输出功率 | 1~60 | |
| Power stability (rms, over 4 hours) 功率稳定性 | <1%, <2%, <3% | |
| Pulse width (ps) 脉宽 | 100~1000 (unadjustable) | |
| Transverse mode 输出模式 | Near TEM00 | |
| User trigger frequency频率 | 100kHz~20MHz (Internal trigger available) | 20MHz~80MHz |
| Beam diameter at the aperture (1/e2, mm)光斑尺寸 | ~1.2 | |
| Beam divergence, full angle (mrad)发散角 | ~1.0 | |
| Warm-up time (minutes)上升时间 | <5 | |
| Beam height from base plate (mm)中心高 | 26.5 | |
| Operating temperature (℃)工作温度 | 10~35 | |
| Operating voltage电压 | DC12V 4A | |
| Warranty保修期 | 1 year | |
